Hikvision DS 2CE56D8T VPITE AHD Bullet Kamera
Özellikler
Teknik Özellikler
Camera | |
Image Sensor | 2MP CMOS Image Sensor |
Signal System | PAL/NTSC |
Effective Pixels | 1920(H)*1080(V) |
Shutter Time | 1/25(1/30) s to 1/50,000 s |
Lens Mount | M12 |
Adjustment Range | Pan: 0° to 360°, Tilt:0° to 75°, Rotate: 0° to 360° |
Day& Night | IR cut filter with auto switch |
Wide Dynamic Range | 120dB |
Video Frame Rate | 1080p@25fps/1080p@30fps |
HD Video Output | 1 Analog HD output |
Synchronization | Internal Synchronization |
Up the Coax | Support |
Menu | |
Auto White Balance | Auto/MWB |
BLC | Support |
AGC | Support |
Language | English/Chinese |
General | |
Operating Conditions | -40 °C - 60 °C (-40 °F - 140 °F) |
Humidity 90% or less (non-condensing) | |
Power Supply | 12 VDC±25%/PoC.af |
Impact Protection | IK10. |
Weather Proof | IP67 |
IR Range | Up to 20m |
Communication | Up the coax |
Protocol: HIKVISION-C(Coaxitron) | |
Dimension | φ111mm×82.5mm (φ0.43”×3.25”) |
Weight | Approx. 350g ( 0.77lb) |
Hikvision DS 2CE56D8T VPITE AHD Bullet Kamera Pdf Dosyası895.92 KB
Hikvision DS 2CE56D8T VPITE AHD Bullet Kamera Kullanıcı Kılavuzu (ing) Pdf Dosyası2.4 MB
