| Camera |
| Pixel | 5MP |
| Image Sensor | 5MP CMOS |
| Max. Resolution | 2880 (H) × 1620 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/3 s–1/100000 s |
| NTSC: 1/4 s–1/100000 s |
| Min. Illumination | 0.001 lux@F1.0 (Color, 30 IRE) |
| 0.0001 lux@F1.0 (B/W, 30 IRE) |
| 0 lux (Illuminator on) |
| S/N Ratio | >65dB |
| Illumination Distance | IR: 40 m (131.23 ft) |
| Warm light: 40 m (131.23 ft) |
| Illuminator On/Off Control | Auto; manual |
| Illuminator Number | 2 (IR light) |
| 2 (Warm light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° |
| Tilt: 0°–78° |
| Rotation: 0°–360° |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F1.0 |
| Field of View | 2.8 mm: H: 111°; V: 57°; D: 131° |
| | 3.6 mm: H: 89°; V: 47°; D: 104° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 1.5 m (4.92 ft) |
| 3.6 mm: 2.2 m (7.22 ft) |
| DORI distance | Lens | Detect | Recognize | Identify |
| 2.8 mm | 66.0 m(216.54 ft) | 13.2 m(43.31 ft) | 6.6 m(21.65 ft) |
| 3.6 mm | 78.0 m(255.91 ft) | 15.6 m(51.18 ft) | 7.8 m(25.59 ft) |
| Video |
| Video Frame Rate | CVI: |
| PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps |
| NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps; |
| AHD: |
| PAL: 4M@25 fps; |
| NTSC: 4M@30 fps; |
| TVI: |
| PAL: 4M@25 fps; |
| NTSC: 4M@30 fps; |
| CVBS: |
| PAL: 960H; |
| NTSC: 960H |
| Resolution | 5M (2880 × 1620); |
| 4M (2560 × 1440); |
| 1080p (1920 × 1080); |
| 960H (960 × 576/960 × 480) |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | BLC; HLC; WDR; HLC-Pro |
| WDR | 120 dB |
| White Balance | Auto; Area white balance |
| Gain Control | Auto; manual |
| Noise Reduction | 3D NR |
| Defog | Electronic defog |
| Digital Zoom | 4× |
| Mirror | Yes |
| Privacy Masking | Off/On (8 areas, rectangle) |
| Illumination Mode | Smart IR&WL; WL Mode; IR Mode |
| Certifications |
| Certifications | CE (EN55032:2015, EN61000-3-2:2014, EN61000-3-3:2013, EN55024:2010+A1:2015, EN55035:2017, EN50130-4:2011+A1:2014, EN62368-1:2014+A11:2017) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL62368-1+CAN/CSA C22.2 No.62368-1-14) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input | One channel built-in MIC |
| Power |
| Power Supply | 12 VDC ± 30% |
| Power Consumption | Max 5.7 W (12 VDC, LED on) |
| Environment |
| Operating Temperature | –40 °C to +60 °C (–40 °F to 140 °F) |
| Operating Humidity | <95% (RH), non-condensing |
| Storage Temperature | –40 °C to +60 °C (-40 °F to 140 °F) |
| Protection | IP67 |
| Structure |
| Casing Material | Metal |
| Product Dimensions | Φ106.0 mm × 93.6 mm (Φ4.17" × 3.69") |
| Packaging Dimensions | 148 mm × 139 mm × 137 mm (5.83" × 5.47" × 5.39") |
| Net Weight | 0.49 kg (1.08 lb) |
| Gross Weight | 0.66 kg (1.46 lb) |
| Installation | Wall mount; ceiling mount; vertical pole mount |
