| Video Compression: | H.264 |
| HD-SDI video input: | 1-ch, HD-SDI (800mVp-p, 75Ω) |
| | 1920×1080P/25Hz, 1920×1080P/30Hz, 1920×1080I/50Hz, 1920×1080I/60Hz, 1920×720P/25Hz, |
| | 1280×720P/30Hz, 1920×720P/50Hz, 1280×720P/60Hz |
| FC video input: | Resolution: 1920×1080P/25Hz, 1280×720P/25Hz, 1600×1200/25Hz |
| HDMI video input: | 1-ch, Resolution: 1600×1200/60Hz, 1920×1080P/60Hz, 1280×720P/60Hz, 1280×1024/60Hz, |
| | 1024×768/60Hz |
| VGA video input: | 1-ch, Resolution: 1600×1200P/60Hz, 1920×1080P/60Hz, 1920×1080P/50Hz, 1280×720P/60Hz, |
| | 1280×1024/60Hz, 1024×768/60Hz |
| YPbPr video input: | 1-ch, Resolution: 1920×1080I/60Hz, 1920×1080I/50Hz,1920×1080P/25Hz, 1920×1080P/30Hz, |
| | 1280×720P/60Hz, 1280×720P/50Hz |
| Audio compression: | G.711 |
| Audio input: | 1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Two-way audio: | 1-ch, RCA (2.0Vp-p, 1kΩ) |
| Audio output: | 1-ch, RCA (Linear, 1 kΩ) |
| Encoding resolution: | 1920×1080/1600×1200/1280×1024/1280×720/1024×768/704×576/352×288(depending on the type of video input interface connected) |
| Frame rate: | 1/16~25/30/50/60 fps |
| Video bit rate: | 32 Kbps ~ 16 Mbps |
| Dual Stream: | Support |
| Stream Type: | Video/ Video&Audio |
| Protocols Supported: | TCP/IP, UDP, IPv4, IPv6; HTTP, RTP, RTSP, NFS, ISCSI, DHCP, NTP, SMTP, SNMPv1, SNMPv2c, |
| | SNMPv3, UPNP, SADP, PPPoE, DNS, FTP; IP Server, Dyndns, PeanutHull, NO-IP; PSIA. |
| Type: | 8 network disks (NAS/IP SAN) |
| Capacity: | Up to 2TB capacity for each disk. |
| Network interface: | 1 RJ45 10/100/1000Mbps self-adaptive UTP Ethernet interface |
| Serial interface: | 1 RS-485, 1 RS-232 |
| Alarm in: | 2 |
| Alarm out: | 1 |
| Power supply: | 12 VDC |
| Consumption: | ≤ 13W |
| Working temperature: | -10°C~+55°C(14°F~131°F) |
| Working humidity: | 10%~90% |
| Dimension(W×D×H): | 200 × 123 × 39 mm (W × D × H) |
| Weight(without HDD): | ≤ 1.5 kg |
