| DSP | NEXTCHIP NVP2441H |
| Imaging Device | 1/2.8'' IMX322+NEXTCHIP2441 |
| Total Pixels | 1920(H) x 1080(V) |
| Scanning System | Progressive Scan |
| Synchronization | Internal |
| Video Output P/N | AHD 2.4MP 1080P |
| Lens | 6-60 mm Varifocal Lens |
| IR Led | 2 Adet Array Led (IR Range 30-100 Metre) |
| S/N Signal | ＞46db |
| Min. IIIumination | （Color）：0.05LUX （F1.2，501RE） |
| （B/W）：0LUX （F1.2，501E） |
| ESC | 1/50（60）~1/100，000（120，000）sec |
| OSD Language | CHN1,CHN2,GER,FRA,ITA,SPA, |
| POL,RUS,POR,NED,TUR,ENG |
| BLC | BLC/HLC/D-WDR |
| Day/Night Selection | Color/Auto (D/N) /B/W/EXT |
| Gain Control | 0db-42db |
| Whtie Balance | ATW(2700°K~10500°K) |
| AWC-SET/INDOOR/OUTDOOR/MANUAL /AWB |
| Motion Detenction | On/Off (Programmable 4 Zones) |
| Privacy Making | On/Off (Programmable 4 Zones) |
| DNR | 2DNR/3DNR |
| Digital Effect | （FREEZE） |
| (U/D/L/R,MIRROR |
| Input Voltage | DC 12V |
| Power Consumption | Max 4w |
| Operating Temp/Hum | -20℃ ~ 65℃ / 30%RH ~ 95%RH |
| Storage Temp/Hum | -20℃ ~ 65℃ / 30%RH ~ 95%RH |
