| Camera |
| Image Sensor | 2MP CMOS Image Sensor |
| İşaret Sistem | PAL/NTSC |
| Etkin Piksel | 1920(H)*1080(V) |
| Min. Illumination | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/25(1/30) s to 1/50,000 s |
| Lens | 2.8 mm, 3.6 mm, 6 mm |
| Lens Mount | M12 |
| Ayarlama Aralık | Pan: 0°to 360°, Tilt: 0°to 180°, Rotation: 0°to 360 |
| Day& Night | IR cut filter with auto switch |
| Video Frame Rate | 1080p@25fps/1080p@30fps |
| HD Video Çıkışı | 1 Analog HD output |
| Senkronizasyon | Internal Synchronization |
| S / N Oranı | More than 62 dB |
| General |
| Operating Conditions | -40 °C - 60 °C (-40 °F - 140 °F) |
| Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC±15% |
| Power Consumption | Max. 4 W |
| Weather Proof | IP66 |
| IR Range | Up to 20m |
| Boyutlar | ? 85.4 mm × 76.12 mm (? 3.38" × 2.67") |
| Ağırlık | 190 g (0.42 lb.) |
