| Camera |
| Image Sensor : 1/3" Progressive Scan CMOS |
| Min. Illumination : 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter time : 1/3s~1/100,000s |
| Lens : 4mm, horizontal view angle 63°(2.8mm/6mm/8mm optional) |
| Lens Mount : M12 |
| Adjustment Range : H: -30°~30°, V: 0°~80°, R: 0°~360° |
| Day& Night : IR cut filter with auto switch |
| Wide Dynamic Range : Digital WDR |
| Digital noise reduction : 3D DNR |
| Compression Standard |
| Video Compression : H.264/MJPEG |
| H.264 code profile : Base Line Profile/Main Profile |
| Video bit rate : 32Kbps~8Mbps |
| Audio Compression : G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate : 64Kbps(G.711)/16Kbps(G.722.1)/32-128Kbps(MP2L2) |
| Dual Stream : Yes |
| Image |
| Max. Image Resolution : 1920 x 1080 |
| Frame Rate : 50Hz: 25fps (1920*1080,1280 × 960,1280 × 720)/60Hz: 30fps (1920*1080,1280 × 960,1280 × 720) |
| Image Settings : Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC : Yes, zone configurable |
| ROI : support |
| 3D DNR : support |
| Network |
| Network Storage : Micro SD/SDHC/SDXC card with ANR (up to 64G), NAS (Support NFS, SMB/CIFS) |
| Alarm Trigger : Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protocols:TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP, DNS, DDNS,RTP, RTSP,RTCP, PPPoE,NTP,
UPnP,SMTP,SNMP, IGMP,802.1X,QoS,IPv6,Bonjour |
| General Function : User Authentication, Watermark, IP address filtering, anonymous access, flickerless, heartbeat, video mask |
| System Compatibility : ONVIF, PSIA, CGI, ISAPI |
| Interface |
| Audio : Internal Microphone and Speaker |
| Communication Interface : 1 RJ45 10M / 100M Ethernet interface |
| On-board storage : Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
| General |
| Operating Conditions : -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
| Power Supply : 12 V DC ± 10%, PoE (802.3at) |
| Power Consumption : 5.5W MAX |
| Impact Protection : IK08 Protection Level |
| Weather Proof : IP66 |
| IR Range : 10 meters |
| Dimensions : 99.3x96.7x52.8mm (3.91” × 3.81” × 2.08”) |
| Weight : 600g (1.32lb) |
