| Camera |
| Sensor | 1/2.7” HD progressive scan CMOS |
| Lens | 3.6 mm megapixel fixed focal length lens |
| Angle of View | • 3.6 mm, F1.6: Diagonal 120°, Horizontal 96°, Vertical 56° |
| Minimum Illumination | 0.2 Lux @ F=1.2 |
| Synchronization | Internal |
| White Balance | ATW/AWB |
| Electronic Shutter | Auto (1/30 to 1/25000 sec) |
| S/N Ratio | 50 dB (Gamma, Aperture, AGC, OFF; DNR ON) |
| DNR | Built-in DNR |
| WDR | Level 1-3, up to 115 dB |
| AGC (auto gain control) | 2X, 4X, 8X, 16X |
| Flickerless Control | Automatic/50 Hz/60 Hz mode |
| Auto Exposure | Level ±5 |
| Image Rotation | Flip, Mirror, and 180° rotation |
| Image Setting | Manual tuning with brightness and contrast |
| Video |
| Video Compression | H.264 (ISO/IEC 14496-10) or MJPEG |
| Video Output | via Ethernet |
| Video Streams | 3 independent H.264 or MJPEG video streams |
| • Stream 1: H.264, 1280 x 800 resolution (max.) |
| • Stream 2: H.264, 720 x 576 resolution (max.) |
| • Stream 3: MJPEG, 720 x 576 resolution (max.) |
| Note: Streams 2 and 3 must be set to the same resolution |
| Video Resolution and FPS (frames per second) |
| Video Viewing | • DynaStream™ support for automatic frame rate adjustment |
| • CBR Pro™ for good image quality in limited bandwidth transmission |
| • 3 privacy mask areas configurable |
| • Adjustable image size and quality |
| • Timestamp and text overlay |
| • OSD (On scre |
| Audio |
| Audio Inputs | 1, built-in microphone |
| Audio Format | Mono, PCM (G.711) |
| Network |
| Protocols | TCP/IP, UDP, HTTP, SMTP, NTP, DNS, DHCP, UPnP, RTP, RTSP, ICMP, QoS,IGMPv3, SNMPv1/v2c/v3, DDNS, TFTP, ARP, DHCP, OPT66/67 |
| Ethernet | 1 10/100BaseT(X) isolated Ethernet port, 4-pin M12 D-coded female connector |
| GPIO |
| Digital Inputs | 1, max. 8 mA, isolated 5-pin M12 connector |
| High: +13 V to +30 V; Low: -30 V to +3 V |
| Power Requirements |
| Input | Power-over-Ethernet (IEEE 802.3af) |
| Power Consumption | 6 W (max.) |
| Physical Characteristics |
| Housing | IP66 metal housing with transparent cover |
| Dimensions | 109 x 68 x 90 mm (4.29 x 2.68 x 3.54 in) |
| Weight | 903 g (1.1 lb) |
| Installation | Flush mounting |
| Alarms |
| Intelligent Video | Camera tamper |
| Video Motion Detection | 3 independently configurable motion areas |
| Scheduling | Daily repeat timing schedule |
| Imaging | JPEG snapshots for pre/trigger/post alarm images |
| Custom Alarms | HTTP event servers for setting customized alarm actions |
| Email/FTP Messaging | Automatic transfer of stored images via email or FTP as event-triggered actions |
| Pre-alarm Buffer | 12 MB video buffer for JPEG snapshot images |
| Security |
| Password | User level password protection |
| Filtering | By IP address |
| Encryption | HTTPS, SSH |
| Environmental Limits |
| Operating Temperature | -25 to 55°C (-13 to 131°F) |
| Storage Temperature | -40 to 75°C (-40 to 167°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| Altitude | 2000 m |
| Conformal Coating | Available on request |
| Standards and Certifications |
| Safety | UL 60950-1 |
| Rail Traffic | EN 50155*, EN 45545-2 |
| *This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard. For a more detailed statement, click here: www.moxa.com/doc/specs/EN_50155_Compliance.pdf |
| EMI | FCC Part 15, CISPR (EN 55032) class A |
| EMS | IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV |
| IEC 61000-4-3 RS: 80 MHz to 1 GHz: 20 V/m |
| IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV |
| IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV |
| IEC 61000-4-6 CS: 10 V |
| IEC 61000-4-8 |
| Shock | IEC 61373 |
| Freefall | IEC 60068-2-32 |
| Vibration | IEC 61373 |
| Note: Please check Moxa’s website for the most up-to-date certification status. |
| Warranty |
| Warranty Period | 5 years |
| Details | See www.moxa.com/warranty |
| Minimum Viewing System Requirements |
| CPU | Pentium 4, 2.4 GHz |
| Memory | 512 MB of memory |
| OS | Windows XP/2000 with SP4 or above, Windows Vista, Windows 7 |
| Browser | Internet Explorer 9.x or above |
| Multimedia | DirectX 9.0c or above |
| Software Development |
| VPort SDK PLUS | Includes CGI commands, ActiveX Control, and API library for customized applications or system integration for third-party developers (the latest version of SDK is available for download from Moxa’s website). |
| Standard | ONVIF |
