Özellikler
- Vandal Resistant Dome (IK10)
- 3 Axis Gimbal, 2 ways to mount: Wall/Ceiling Flat and Flush
- TAMRON Varifocal Lens: f = 2.8 - 10.5 mm, auto iris
- Fast & easy Zoom/Focus adjustment mechanic
- Remote Control Interfaces over Coax (Coaxitron)
- Built-in Service Monitor Port & OSD Control Port
- Video Enhancement: BLC, HLC, DNR, DIS
- Extended Temperature range -25°C ~ +55°C
- Support Dual Power AC24V/DC12V
Teknik Özellikler
- Image Sensor: 1/3" CCD Sony 960H Ex-view HAD II
- Scanning System: PAL, 50Hz, 2:1 Interlace
- Pixels - Effective: 976(H) x 582(V)
- Resolution: 650 (H) lines colour, 700 (H) lines b&w
- Col/B&W: Auto, Color, Removable IR-Cut Filter (ICR)
- Sensitivity Colour: 0.4 Lux(50IRE) @ F1.2 (SensUp=0, AGC Off), 0.000007Lux 15IRE @ F1.2(SensUpx512)
- Sensitivity B&W: 0 Lux LED IR on
- S/N Ratio: >52 dB
- Lens Focal Length: 2.8 ~ 10.5 mm (TAMRON)
- Horizontal Viewing Angle: 102° (Wide) ~ 27° (Tele)
- Lens Drive Type: Auto iris (DC)
- Iris F-Number: F= 1.2 ~ 360
- Sens Up: Off ~ x512, auto
- Motion Detection: On/ Off/ Sensitivity/ 4 Area setting
- Number of Privacy Zones: 15 (polygonal method)
- High Speed Shutter: 1/50 ~ 1/10.000 sec, auto
- AGC: 6~44.8dB
- ATR (Adaptive Tone Reproduction): On/Off
- BLC Back Light: On/Off/HLC
- Digital Noise Reduction (DNR): On/Off (1~6 level)
- Digital Image Stabilization (DIS): Off/On
- Reverse: Off/ H-REV/ V-REV/ HV-REV
- OSD: Yes (DE,EN,FR,IT,RU,TR)
- Camera ID: 52 character over 2 lines
- White Balance: ATW/Push/User1/User2/AntiCR/Manual/Push Lock
- IR LED: 28 pcs.
- Optical Wavelength: 850 nm
- Max. IR Distance: 15/30 m (according to scene reflexion)
- Protection Rating: IP67/IK10
- Remote Control: Coaxitron, data on coax cable
- Accessories included: Multi-Language Manual, Template, Cable for Service Monitor, Screws, screw driver for Zoom and Focus adjustment
- Humidity: less than 90%, non condensing
- Operating Temperature: -25°C ~ +55°C
- Supply Voltage: 12 Vdc / 24 Vac
- Power Consumption: 5.8 (LED on) W
- Weight: 1.12 kg
- Dimensions w*h*d: Ø 150 x 124 mm
Grundig GCA B5326V Dome Kamera PDF Dosyası182.37 KB
