| Kamera |
| Görüntü Sensörü | 1/4” EXview HAD CCD |
| Effective Pixels | 752(H) x 582(V) / 768(H) x 494(V) |
| Yatay Çözünürlük | 540TVL |
| Scanning System | Interlacing |
| Electronic Shutter Speed | 1/3(4) ~ 1/10000 sec (20 steps) |
| Min. Aydınlatma | 0.7Lux/F1.8 |
| S/N Oranı | >50dB |
| Video Çıkış | BNC(1.0Vp-p/75Ω), PAL / NTSC |
| Camera Features |
| Day/Night | Auto(ICR) / Color / B/W |
| Arka Işık Telafisi | BLC |
| Beyaz Denge | Auto, ATW, Indoor, Outdoor, Manual |
| Kazanç Kontrolü | Auto / Manual |
| Digital Zoom | 12x |
| Lens |
| Focal Length | 3.8mm~38.0mm (10x optical zoom) | 4.2mm~42.0mm (10x optical zoom) |
| Max Aperture | F1.8~F2.9 |
| Focus Control | Auto / Manual |
| Angle of View | H: 51.2°~5.6° |
| Close Focus Distance | 200mm~1000mm |
| PTZ |
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -0° ~ 90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1° ~ 200°/s; Tilt: 0.1° ~120°/s |
| Preset Speed | Pan: 300; Tilt:150°/s |
| Preset | 80(DH-SD) , 200(Pelco-P/D) |
| PTZ Mode | 5 Auto Scan, 8 Tour, 5 Pattern |
| Protocol | DH-SD, Pelco-P/D |
| Yedekleme Arayüzü |
| RS485 | 1 port |
| Genel |
| Güç Kaynağı | AC24V/1A (±10%), DC12V optional |
| Güç Tüketimi | 12W |
| Çalışma Sıcaklığı | -10~50ºC / Less than 90% RH |
| Boyutlar | Φ154.4(mm) x 169(mm) |
| Ağırlık | 1.5kg |
