Özellikler
- 12x motorized optical zoom with 12x digital zoom
- 650 TV Lines
- High Speed Pan/Tilt (400°/sec), minimum speed (0.5°/sec)
- WDR function, Colour/B&W function with removable IR cut filter
- Digital Image Stabilization
- Digital Noise Reduction
Teknik Özellikler
- Image Sensor: 1/4" CCD (Super HAD II)
- Pixels - Total: 976x582 (570k)
- Resolution: 650 (H) lines
- Sensitivity: 0.1 lux (Colour) / 0.01 lux (B&W)
- Shutter Speed: 1 ~ 1/10.000 sec
- Col/B&W: On/Off/Auto, IR-cut filter removable (ICR)
- Optical Zoom Ratio: 12x
- Focal Length: 3.8 ~ 45.6 mm
- Iris Operation: Auto, Manual
- Lens Drive Type : Auto iris (DC)
- Aperture Ratio: F 1.6 ~ C
- Auto Flip: Image/Mechanic/Off
- OSD: Yes (EN,DE,FR,ES,IT,PT)
- Camera ID: 20 character
- Digital Image Stabilization (DIS): Off/On
- WDR: On/Off
- BLC Back Light: On/Off
- White Balance: Auto, Manual, Indoor, Outdoor
- Digital Noise Reduction (DNR): 2DNR/3DNR (Off/On)
- AGC: Auto, Manual
- Number of Privacy Zones: 16
- Digital Zoom: Off/1 ~ 12x
- Number of Preset: 256
- Sequence: 8
- Cruise: 8
- Autopan: 4
- Home position: Preset/Sequence/Auto Pan/Cruise
- Pan Speed: Manual: 1°/s ~ 80°/s, Preset: 400°/s (max.)
- Tilt Speed: Manual: 0.5°/s ~ 90°/s,Preset: 400°/s (max.)
- Range Panning: 360° endless
- Range Tilting: -10° ~ 190°
- Preset Accuracy: 0.225°
- Alarm Inputs: 8
- Alarm Outputs: 1
- Alarm functions: Preset/Sequence/Auto Pan/Cruise
- Serial Interface(s): RS-485/422
- Protocol: Pelco P, Pelco D, AD422, Philips, Kalatel, VCL,JVC, DSCP
- Operating Temperature: 0°C ~ +40°C
- Humidity: less than 90%, non condensing
- Supply Voltage: 24 Vac / 24 Vdc ±10%
- Regulation: CE, RoHS Compliant
- Power Consumption: 18 W
- Weight: 1.2 kg
- Dimensions w*h*d: ø131 x 200 mm
Grundig GCA C0335P Speed Dome Kamera PDF Dosyası238.51 KB
