Sinyal Sistemi | NTSC |
Görüntü Sensörü | 1/4" Interline Transfer CCD |
Lens | 23x Optical (12x Digital) |
f/1.6 at 3.6-82.8mm |
Number of Pixels | 380 |
Yatay Çözünürlük | 470 TV Lines |
Lux | 0.02 lux, Auto 1/4 s, IR Off |
0.3 lux, Auto 1/60 s, IR Off |
0.2 lux, Auto 1/4 s, IR On |
3 lux, Auto 1/60 s, IR On |
Sinyal Gürültü Oranı | >50 dB |
Controls | Adjustable to 30 dB |
Iris Operation | Auto/Manual |
Pan Angle | 360° |
Pan Speed | 0.1-360°/s |
Tilt Angle | -2.5° above Horizon |
92.5° (-2.5° past Vertical) |
Tilt Speed | 0.1-150°/s |
Preset Positions | 79 Programmable Presets |
Signal Connectors | Video Out: RJ-45 (Ethernet) |
Relay Output: 3-Position Removable Screw |
Audio: 1/8" Phono Jack (x2) |
Sync System | Internal/External (Line Lock on AC Line) |
Güç Gereksinimi | 18-30 VAC |
Güç Tüketimi | Coax, Fiber, UTP: 24W |
ViconNet (TCP/IP): 34W |
Çalışma Sıcaklığı | 32-132°F (0-55°C) |
Boyutlar | Diameter: 8" (20.3 cm) |
Height: 9.7" (24.6 cm) |
Ağırlık | 4.7 lb (2.1 kg) |
