System |
Time Accuracy : 5ppm (12.5sec/month) |
Time Sync. : NTP, GMT, DST, Time Server |
User : 15 Users (Admin., User1 ~ User14) |
Video |
Input : 16 BNC |
Output : 1 HDMI, 1 VGA, 1 BNC |
Loop : 16, 8 BNC |
Spot : 1 BNC - Multi-channel (16/9/4/1) |
Audio |
Input : 16 RCA |
Output : HDMI, RCA |
Video Recording |
Resolution : AHD: 720P, 960H: 960H,D1,CIF |
Quality : 5 Levels |
Audio Recording |
Compression : G.711U |
Network |
Interface : Ethernet 10/100/1G |
Compression : H.264 |
Speed : Max. 720P 10fps/ch |
Resolution : Max. 720P |
Alarm |
Pre/Post-Alarm : 5sec / 5sec~5min |
Motion Grid : 14 x 15 (NTSC/PAL) |
Input / Output : 8/2 - NC/NO/EOL |
Display |
HDMI : Full HD, XGA |
VGA : Full HD, XGA |
TV : SDTV(720x480/576) |
External Interface |
PTZ / Keyboard : 2 RS485 - Terminal Block |
ATM / POS : RS232C - Terminal Block, Ethernet POS |
Storage |
Primary, External : 3 HDD & 1 eSATA |
General |
OS : Embedded Linux |
Dimension : 430 x 86 x 270 mm |
Net Weight(w/o HDD) : 4Kg |
Power Supply : 12V/5A - Level 5 |
Consumption : 60Watts |
Operating Temp : 5 ~ 40˚C |
Humidity : 10 ~ 80% |
