| System |
OS |
Embedded Linux |
| Language |
Chinese, Chinese(S), Dutch, English, French, German, Hebrew, Hungari, Italian, Japanese, Korean, Latvian, Persian, Polish, Portuguese, Russian, Spanish, Sweden, Turkish, Arabic |
| Time Accuracy |
5ppm (12.5sec/month) |
| Time Sync. |
NTP, GMT, DST, Time Server |
| User |
15 Users (Admin., User1 ~ User14) |
| Camera |
IP Camera |
ONVIF Profile S |
| Video |
System |
NTSC / PAL |
| Input |
32 BNC / 16 BNC |
| IPC Input |
16 IPC / 8 IPC |
| Output Interface |
HD-MI, VGA, BNC |
| Spot |
HD-TVI spot, SD spot |
| Audio |
Input Interface |
16 RCA |
| Output Interface |
1 HD-MI, 1 RCA |
| Video |
Compression |
H.264 |
| Recording |
Speed |
15fps/ch, 30fps/ch |
| Resolution |
TVI(720p, 1080p, 3MP, 4MP), AHD(720p,1080p, 3MP, 4MP), CVI(720p, 1080p), Analog SD(960H), IP(Max. 4MP) |
| Quality |
5 Levels |
| Audeo |
Compression |
G.711u |
| Recording |
| Playback |
Search |
Go to first rec. time, Go to last rec. time, |
| Go to last search time, |
| Calendar, Log viewer, Smart search, |
| Multi-time & day search, Event search |
| Mode |
Event only playback, Backward, |
| Pause, Frame by frame, Speed up (x1 ~ x32, x300) |
| Network |
Interface |
RJ45 (Ethernet 10/100/1G) x 2 |
| Compression |
H.264 |
| Speed |
Max. 1080p 15fps/ch |
| Resolution |
Max. 2MP(1080p) |
| Backup |
Interface |
USB, Network |
| Format |
RMS, AVI |
| Alarm |
Post-Alarm |
5sec~5min |
| Motion Grid |
32 x 24 |
| Alarm Action |
E-mail, Event Popup, Buzzer, Relay, |
| PTZ Preset,Remote VMS, Front LED |
| Input / Output |
16/4 - NC/NO |
| Display |
HD-MI |
Full HD, XGA |
| TV |
SDTV(720x480) |
| Mode |
32/16/9/4/1/SEQ/BIG - LIVE, 32/16/9/4/1 - P.B |
| 16/9/4/1/SEQ/BIG - LIVE, 16/9/4/1 - P.B |
| External |
PTZ / Keyboard |
2 RS485 - Terminal Block |
| Interface |
ATM / POS |
RS232C - Terminal Block, Ethernet POS |
| Storage |
Primary |
6 HDD |
| External |
2 eSATA |
| Genaral |
Power Supply |
90~250V, 50/60Hz |
| Consumption |
80W |
| Operating Temp. |
5 ~ 40?C |
| Humidity |
10 ~ 80% |
| Weight w/o HDD |
8Kg |
| Dimension |
440 x 88 x 430 mm |
| Certification |
CE, FCC, RoHS Compliance |
