| Video/Audio Input |
| Audio Input: |
16-ch |
| Video Compression: |
H.264 |
| Analog Video Input: |
24-ch |
| PAL/NTSC Adaptive: |
Support |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
G.711u |
| Audio Input Interface: |
16-ch, RCA (2.0 Vp-p, 1 kΩ) / DB26 connector |
| Two-way Audio: |
1-ch RCA(2.0Vp-p, 1kΩ) |
| Video/Audio Output |
| VGA Output: |
1-ch, resolution: |
| |
1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz |
| CVBS Output: |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Recording resolution: |
WD1/ 4CIF / 2CIF / CIF / QCIF |
| Frame Rate: |
WD1 / 4CIF: 15fps |
| |
2CIF / CIF / QCIF: 25 fps (P) / 30 fps (N) |
| Video Bit Rate: |
32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps) |
| Stream Type: |
Channel 1-16: Video, Video |
