| Sistem |
| İşlemci | Dual-core embedded processor |
| İşletim Sistemi | Embedded LINUX |
| Video |
| Giriş | 4 Kanal, BNC |
| Standard | NTSC/ PAL, Effio 960H camera |
| Loop Çıkışı | 4 channel |
| Ses |
| Giriş | 4 Kanal, BNC |
| Çıkış | 1 Kanal, BNC |
| Çift Yönlü Konuşma | 1 Kanal Input, 1 Kanal Output, BNC |
| Görüntüleme |
| Arayüz | 1 HDMI, 1 VGA, 1 TV, 1 Spot, BNC(1.0Vp-p, 75Ω) |
| Çözünürlük | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Görüntü Bölmesi | 1/4 |
| Gizlilik Maskesi | 4 rectangular zones (each camera) |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Kayıt |
| Video/Ses Sıkıştırma | H.264 / G.711 |
| Çözünürlük | 960H(960×576/960×480)/D1/4CIF(704×576/704×480) / HD1(352×576/352×480) /2CIF(704×288/704×240) / CIF(352×288/352×240) / QCIF(176×144/176×120) |
| Kayıt Hızı | Main Stream: | 960H/D1/HD1/2CIF/CIF(1~25/30fps) |
| Extra Stream | CIF/QCIF(1~25/30fps) |
| Bit Hızı | 48~4096Kb/s |
| Kayıt Modu | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Algılama & Alarm |
| Trigger Events | Kayıt, PTZ, Tour, Alarm, Video Push, Email, FTP, Spot, Buzzer & Screen tips |
| Video Algılama | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
| Alarm Girişi | 4 Kanal |
| Röle Çıkışı | 6 Kanal |
| Oynatma & Yedekleme |
| Sync Playback | 1/4 |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file,Next camera, Previous camera, Full screen, Repeat,Shuffle, Backup selection, Digital zoom |
| Yedekleme Modu | USB Device / eSATA Device / Internal SATA burner/ Network |
| Network |
| Ethernet | 2 RJ-45 ports (10/100M/1000M) |
| Network Functions | HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP,DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server |
| Max. User Access | 20 users |
| Akıllı Telefon | iPhone, iPad, Android, Windows Phone |
| Depolama |
| Dahili HDD | 8 SATA ports (8HDDs or 6HDDs+1CD/DVD-RW), up to 32TB |
| Harici HDD | 1 eSATA port (Max 4 SATA HDDs), up to 16TB |
| Yedekleme Arayüzü |
| USB Arayüzü | 4 ports (2 Rear), USB2.0 |
| RS232 | 1 port, For PC communication & Keyboard |
| RS485 | 1port, For PTZ control |
| Genel |
| Güç Kaynağı | AC100~240V, 50/60Hz |
| Güç Tüketimi | 25W |
| Çalışma Ortamı | -10 ~+55°C / 10~90%RH / 86~106kpa |
| Boyutlar(W×D×H) | 2U, 440mm×460mm×89mm |
| Ağırlık | 6.5KG(without HDD) |
