| Video/Audio Input |
| Audio Input: | 1-ch |
| Video Compression: | H.264 |
| Analog Video Input: | 4-ch |
| PAL/NTSC Adaptive: | Support |
| IP Video Input: | 1-ch 720P |
| Video Input Interface: | BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: | G.711u |
| Audio Input Interface: | RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input) |
| Video/Audio Output |
| VGA Output: | 1-ch, resolution: |
| | 1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz |
| CVBS Output: | 1-ch, BNC (1.0 Vp-p, 75 Ω), |
| | resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Recording resolution: | WD1/ 4CIF / 2CIF / CIF / QCIF |
| Frame Rate: | 25 fps (P) / 30 fps (N) |
| Video Bit Rate: | 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps) |
| Stream Type: | Video/Video&Audio |
| Audio Bit Rate: | 64kbps |
| Dual Stream: | Support |
| Synchronous Playback: | 4-ch |
| Hard Disk Driver |
| Interface Type: | 1 SATA Interface |
| Capacity: | Up to 4TB capacity for each disk |
| External Interface |
| Network Interface: | 1 RJ45 10M/100M adaptive Ethernet Interface |
| USB Interface: | 2 USB 2.0 Interfaces |
| Serial Interface: | 1 RJ45 RS-485 half-duplex interface |
| General |
| Power Supply: | 12 VDC |
| Consumption: | ≤ 10 W |
| Working Temperature: | -10 °C ~ +55 °C |
| Working Humidity: | 10% ~ 90% |
| Chassis: | Standalone 1U chassis |
| Dimensions: | 315 × 230 × 45 mm (W × D × H) |
| Weight: | ≤ 2 kg (without hard disk or DVD-R/W) |
