| Video Compression: |
H.264 |
| Video Input: |
4-ch |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
OggVorbis |
| Audio Input: |
4-ch |
| Audio Input Interface: |
BNC (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: |
1-ch (Audio In) |
| Live View Resolution: |
PAL: 704x576; NTSC: 704x480 |
| VGA Output: |
1-ch, resolution: 800x600/60Hz, 1024x768/60Hz, 1280x1024/60Hz |
| Recording resolution: |
4CIF/DCIF/2CIF/CIF/QCIF |
| Video output: |
1-ch, BNC(1.0Vp-p, 75Ω) |
| Aux Video Output: |
1-ch, BNC(1.0Vp-p, 75Ω) |
| Frame Rate: |
4CIF: 25(P)/30(N) fps |
| Video Bit Rate: |
32Kbps~2048Kbps, or user-defined (Max.8Mbps) |
| Stream Type: |
Video/Video&Audio |
| Audio Output: |
1-ch BNC(Linear electrical level, 600Ω) |
| Aux Audio Output: |
1-ch BNC(Linear electrical level, 600 Ohm) |
| Audio Bit Rate: |
16kbps |
| Dual Stream: |
Support |
| Synchronous Playback: |
2-ch |
| Interface Type: |
8 SATA Interfaces |
| Capacity: |
Up to 2TB capacity for each disk |
| Network Interface: |
1 RJ45 10M/100M adaptive Ethernet Interface |
| USB Interface: |
1 USB interface, support USB disk, USB HDD and USB CD/DVD-R/W |
| Serial Interface: |
1 RJ45 RS-232 interface；1 RS-485 interface; 2 RS-485 keyboard interface |
| Alarm Input: |
4-ch |
| Alarm Output: |
2-ch |
| Power Supply: |
100~240VAC, 6.3A, 50~60Hz |
| Consumption: |
≤70W (without HDD or DVD-R/W) |
| Working Temperature: |
-10℃ ~ +55℃ |
| Working Humidity: |
10% ~ 90% |
| Dimensions: |
470mm(D)×441mm(W)×90mm(H) |
| Weight: |
≤ 8Kg (without HDD or DVD-R/W) |
