| Analog video input | 04-ch |
| | BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adaptive |
| Audio input | 4-ch,RCA (2.0 Vp-p, 1 KΩ) |
| | Audio 1-8: |
| | RCA (2.0 Vp-p, 1 KΩ) |
| | Audio 5-08: DB26 connector |
| HDMI output | 1920 × 1080 / 60 Hz (1080P), 1920 × 1080 / 50 Hz (1080P), |
| | 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, |
| | 1024 × 768 / 60 Hz |
| VGA output | 1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, |
| | 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Video loop out | 04-ch |
| | BNC (1.0 Vp-p, 75 Ω) |
| Audio output | 2-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Max. remote connection | 128-ch |
| Outgoing bandwidth | 240 Mbps |
| Video compression | H.264 |
| Encoding resolution | Main stream: 4CIF / 2CIF / CIF / QCIF |
| | Sub-stream: CIF / QCIF |
| Frame rate | Main stream: 25 fps (P) / 30 fps (N) |
| | Sub-stream: 25 fps (P) / 30 fps (N) |
| Video bitrate | 32 Kbps ~ 8 Mbps |
| Audio compression | OggVorbis |
| Audio bitrate | 16 Kbps |
| Stream type | Video, Video & Audio |
| Dual-stream | Support |
| Playback resolution | 4CIF / 2CIF / CIF / QCIF |
| Synchronous playback | 04-ch |
| Record/Capture mode | Manual record/capture, Continuous record/capture, |
| | Motion detection record/capture, Alarm record/capture, |
| | Motion | Alarm record/capture, Motion & Alarm record/capture, |
| | Event record/capture |
| Playback mode | Instant playback, Normal playback, Event playback, Sub-periods playback, |
| | Tag playback, Smart playback,External file playback, Picture playback |
| Backup mode | Normal backup, Event backup, Picture backup |
| Protocol | IPv6, NAT, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, etc. |
| Type | 8 SATA interfaces; 1 eSATA interface |
| Capacity | Up to 6 TB capacity for each disk |
| Array type | RAID0, RAID1, RAID5, RAID10 |
| Number of array | 8 |
| Number of virtual disk | 8 |
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Network interface | 2; 10M/100M/1000M self-adaptive Ethernet interface |
| Serial interface | RS-232, RS-485, Keyboard |
| USB port | 3 × USB2.0 |
| Alarm in/out | 4 / 2 |
| Power supply | 100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption | Max. 35W |
| Working temperature | -10 ºC ~ +55 ºC (14 ºF ~ 131 ºF) |
| Working humidity | 10%~90% |
| Chassis | 19-inch rack-mounted 2U chassis |
| Dimensions | 445 × 470 × 90 mm (17.5 × 18.5 × 3.5 in) |
| Weight | Approx. 8 kg / 17.6 lb (without hard disk or DVD-R/W) |
