| Video Compression: | H.264 |
| Video Input: | 8-ch |
| Video Input Interface: | BNC (1.0 Vp-p, 75Ω) |
| Live View Resolution: | PAL: 704x576; NTSC: 704x480 |
| VGA Output: | 1-ch, resolution: 800x600/60Hz, 1024x768/60Hz, 1280x1024/60Hz |
| Recording resolution: | 2CIF/CIF/QCIF |
| Video output: | 1-ch, BNC(1.0Vp-p, 75Ω) |
| Video Loop Output: | 8-ch, DB15 |
| Frame Rate: | 2CIF: 8fps; CIF: 25(P)/30(N) fps |
| Video Bit Rate: | 32Kbps~2048Kbps, or user-defined (Max.8Mbps) |
| Stream Type: | Video |
| Interface Type: | 8 SATA Interfaces |
| Capacity: | Up to 2TB capacity for each disk |
| e-SATA Interface: | 1 eSATA high speed backup interface |
| Network Interface: | 1 RJ45 10M/100M adaptive Ethernet Interface |
| USB Interface: | 1 USB interface, support USB disk, USB HDD and USB CD/DVD-R/W |
| Serial Interface: | 1 RJ45 RS-232 interface；1 RS-485 interface; 2 RS-485 keyboard interface |
| Alarm Input: | 16-ch |
| Alarm Output: | 4-ch |
| Power Supply: | 100~240VAC, 6.3A, 50~60Hz |
| Consumption: | ≤70W (without HDD or DVD-R/W) |
| Working Temperature: | -10℃ ~ +55℃ |
| Working Humidity: | 10% ~ 90% |
| Dimensions: | 470mm(D)×441mm(W)×90mm(H) |
| Weight: | ≤ 8Kg (without HDD or DVD-R/W) |
