| Analog video input |
08-ch |
| |
BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adaptive |
| Audio input |
08-ch, |
| |
Audio 1-8: |
| |
RCA (2.0 Vp-p, 1 KΩ) |
| |
Audio 5-08: DB26 connector |
| HDMI output |
1920 × 1080 / 60 Hz (1080P), 1920 × 1080 / 50 Hz (1080P), |
| |
1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, |
| |
1024 × 768 / 60 Hz |
| VGA output |
1920 × 1080 / 60 Hz (1080P), 1600 × 1200 / 60 Hz, |
| |
1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Video loop out |
08-ch |
| |
BNC (1.0 Vp-p, 75 Ω) |
| Audio output |
2-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Max. remote connection |
128-ch |
| Outgoing bandwidth |
240 Mbps |
| Video compression |
H.264 |
| Encoding resolution |
Main stream: 4CIF / 2CIF / CIF / QCIF |
| |
Sub-stream: CIF / QCIF |
| Frame rate |
Main stream: 25 fps (P) / 30 fps (N) |
| |
Sub-stream: 25 fps (P) / 30 fps (N) |
| Video bitrate |
32 Kbps ~ 8 Mbps |
| Audio compression |
OggVorbis |
| Audio bitrate |
16 Kbps |
| Stream type |
Video, Video & Audio |
| Dual-stream |
Support |
| Playback resolution |
4CIF / 2CIF / CIF / QCIF |
| Synchronous playback |
08-ch |
| Record/Capture mode |
Manual record/capture, Continuous record/capture, |
| |
Motion detection record/capture, Alarm record/capture, |
| |
Motion | Alarm record/capture, Motion & Alarm record/capture, |
| |
Event record/capture |
| Playback mode |
Instant playback, Normal playback, Event playback, Sub-periods playback, |
| |
Tag playback, Smart playback,External file playback, Picture playback |
| Backup mode |
Normal backup, Event backup, Picture backup |
| Protocol |
IPv6, NAT, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, etc. |
| Type |
8 SATA interfaces; 1 eSATA interface |
| Capacity |
Up to 6 TB capacity for each disk |
| Array type |
RAID0, RAID1, RAID5, RAID10 |
| Number of array |
8 |
| Number of virtual disk |
8 |
| Two-way audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Network interface |
2; 10M/100M/1000M self-adaptive Ethernet interface |
| Serial interface |
RS-232, RS-485, Keyboard |
| USB port |
3 × USB2.0 |
| Alarm in/out |
16 / 4 |
| Power supply |
100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption |
Max. 40W |
| Working temperature |
-10 ºC ~ +55 ºC (14 ºF ~ 131 ºF) |
| Working humidity |
10%~90% |
| Chassis |
19-inch rack-mounted 2U chassis |
| Dimensions |
445 × 470 × 90 mm (17.5 × 18.5 × 3.5 in) |
| Weight |
Approx. 8 kg / 17.6 lb (without hard disk or DVD-R/W) |
