| Video/Audio Input |
| Audio Input: |
4-ch |
| HD-SDI video input: |
8-ch; HD-SDI interface; (800mVp-p, 75Ω) |
| Video Compression: |
H.264 |
| Supported HD-SDI Camera Types: |
720P/25, 720P/30, 720P/50, 720P/60, 1080P/25, 1080P/30, 1080I/50, 1080I/60 |
| Audio Compression: |
G.711u |
| Audio Input Interface: |
RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio:: |
1-ch RCA(2.0Vp-p, 1kΩ) |
| Video/Audio Output: |
| VGA Output: |
1-ch, resolution : 1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz |
| CVBS Output: |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI Output: |
1-ch, resolution : 1920 × 1080P / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Recording resolution: |
1080P/720P/VGA/4CIF/CIF |
| Frame Rate: |
Main stream: 1/16 fps ~ Real time frame rate Sub-stream: 1/16 fps ~ Real time frame rate |
| Video Bit Rate: |
32 Kbps-6 Mbps |
| Stream Type: |
Video/Video&Audio |
| Audio Output: |
2-ch, RCA (Linear, 1 kΩ) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Support |
| Playback Resolution: |
1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Synchronous Playback: |
8-ch |
| External Interface : |
| Network Interface: |
1 RJ45 10M / 100M / 1000M adaptive Ethernet interfaces |
| USB Interface: |
3 USB2.0 interfaces |
| Serial Interface: |
1RS-485 interface, 1 RS-232 interface, 1 RS-485 keyboard interface |
| Alarm Input:: |
16-ch |
| Alarm Output:: |
4-ch |
| General : |
| Power Supply: |
100 ~ 240VAC, 47 ~ 63HZ |
| Consumption: |
≤ 40W (without hard disk) |
| Working Temperature: |
-10 °C ~ + 55 °C (14 ºF ~ 131 ºF) |
| Working Humidity: |
10%~90% |
| Chassis: |
19-inch rack-mounted 2U chassis |
| Dimensions: |
440 × 390 × 70 mm (17.3 × 15.3 × 2.7 inch) |
| Weight: |
≤ 5kg |
