| System |
| Time Accuracy : 5ppm (12.5sec/month) |
| Time Sync. : NTP, GMT, DST, Time Server |
| User : 15 Users (Admin., User1 ~ User14) |
| Video |
| Input : 16 BNC |
| Output : 1 HDMI, 1 VGA, 1 BNC |
| Loop : N/A |
| Spot : 1 BNC |
| Universal : Yes |
| Audio |
| Input : 16 RCA |
| Output : 1 HDMI, 1 RCA |
| Video Recording |
| Speed : Realtime (max. 30fps/ch) |
| Resolution : 1920x1080p |
| Quality : 5 Levels |
| Bit Rate : Max 8Mbps/Ch |
| Audio Recording |
| Compression : G.711u |
| Network |
| Interface : 10/100/1G |
| Compression : H.264 |
| Speed : Max. 720p 8fps/ch |
| Resolution : Max. 1280x720p |
| Alarm |
| Post-Alarm : 5sec~5min |
| Motion Grid : 14x15(NTSC/PAL) |
| Alarm Action : E-mail, Ch Popup, Buzzer, Relay, PTZ Preset, Spot |
| Input / Output : 4/1 - NC/NO/EOL |
| Display |
| HDMI : Full HD, XGA |
| VGA : Full HD, XGA |
| TV : SDTV (720x480) |
| External Interface |
| PTZ / Keyboard : RS485 - Terminal Block |
| ATM / POS : RS232C - Terminal Block / Ethernet |
| Storage : Primary, External, ODD 3 HDD, 1 eSATA, 1 DVD |
| General |
| OS : Embedded Linux |
| Dimension : 430 x 86 x 270 mm |
| Net Weight(w/o HDD) : 4Kg |
| Power Supply : 12V/5A - Level 5 |
| Consumption : 60Watts |
| Operating Temp : 5 ~ 40˚C |
| Humidity : 10 ~ 80% |
