| Video compression |
H.264+/H.264 |
| Analog video input |
8-ch |
| |
BNC interface (1.0Vp-p, 75 Ω), supporting coaxitron connection |
| Supported HDTVI input |
720p/25Hz, 720p/30Hz |
| Supported AHD input |
720p/25Hz, 720p/30Hz |
| CVBS input |
Support |
| Audio compression |
G.711u |
| Audio input/Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| HDMI/VGA output |
1-ch, 1920 × 1080/60Hz,1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Encoding resolution |
When 720p stream is connected: 720p/WD1/4CIF/VGA (12fps)/CIF |
| |
When 4CIF stream is connected: WD1/4CIF/VGA/CIF |
| Frame rate |
25fps(P)/30fps(N) |
| Video bitrate |
32 Kbps to 4 Mbps |
| Audio output |
1-ch, RCA (Linear, 1KΩ) |
| Audio bitrate |
64 Kbps |
| Dual-stream |
Support |
| Stream type |
Video, Video & Audio |
| Synchronous playback |
8-ch |
| Remote connections |
128 |
| Network protocols |
TCP/IP, PPPoE, DHCP,Hik-connect Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| SATA |
1 SATA interface |
| Capacity |
Up to 6TB capacity for each disk |
| Network interface |
1; RJ45 10M/100Mbps self-adaptive Ethernet interface |
| USB port |
2 × USB2.0 |
| Power supply |
12VDC |
| Consumption |
≤ 12W |
| Working temperature |
-10 ºC to +55 ºC (14 ºF to 131 ºF) |
| Working humidity |
10% to 90% |
| Dimensions(W × D × H) |
200 ×200 ×45mm (7.9 × 7.9 × 1.8 inch) |
| Weight(without hard disks) |
≤ 0.8kg (1.8lb) |
