System |
Main Processor : Embedded processor |
Operating System : Embedded LINUX |
Video |
Input : 8 channel, BNC |
Standard : |
Analog : NTSC/PAL |
HD CVI : 720P HDCVI Camera |
IP : Support 2ch 1080P/720P IP Camera |
Audio |
Input : 1 channel, RCA |
Output : 1 channel, RCA |
Two-way Talk : Reuse audio input/output channel 1 |
Display |
Interface : 1 HDMI, 1 VGA |
Resolution : 1920×1080, 1280×1024, 1280×720, 1024×768 |
Display Split : 1/4/8/9 |
Privacy Masking : 4 rectangular zones (each camera) |
OSD : Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
Video/Audio Compression : H.264/G.711 |
Record Rate : Main Stream: 1*720P(1~25/30fps)+7*(1~15fps)/960H/D1 (1~25/30fps) |
Bit Rate : 96~4096Kb/s |
Record Mode : Manual, Schedule(Regular(Continuous), MD), Stop |
Record Interval : 1~60 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection |
Trigger Events : Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer & Screen tips |
Video Detection : Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
Playback & Backup |
Sync Playback : 1/4/9 |
Search Mode : Time/Date, MD & Exact search (accurate to second) |
Playback Functions : Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom, |
Backup Mode : USB Device/Internal SATA burner/Network |
Network |
Ethernet : RJ-45 port (10/100M) |
Network Functions : HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, SNMP, P2P |
Max. User Access : 128 users |
Smart Phone : iPhone, iPad, Android, Windows Phone |
Storage |
Internal HDD : 1 SATA port, up to 4TB |
Auxiliary Interface |
USB Interface : 2 ports(1 Rear), USB2.0 |
RS485 : 1 port, For PTZ Control |
General |
Power Supply : DC12V/2A |
Power Consumption : 10W(without HDD) |
Working Environment : -10°C ~+55°C / 10%~90%RH / 86~106kpa |
Dimension(W×D×H) : Compact 1U, 260mm×220mm×40mm |
Weight : 0.75KG(without HDD) |
