System |
Main Processor | Embedded Processor |
Operating System | Embedded LINUX |
Display |
Interface | 1 HDMI ,1 VGA |
Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
Multi-screen Display | 4CH: 1/4/6 |
8CH: 1/4/8/9/16 |
16CH: 1/4/8/9/16/25 |
OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Video Detection and Alarm |
Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis |
Alarm input | N/A |
Relay Output | N/A |
Playback and Backup |
Playback | 4CH: 1/4 |
8CH: 1/4/9 |
16CH: 1/4/9/16 |
Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
Backup Mode | USB Device/Network |
Storage |
Internal HDD | 1 SATA Port, up to 8TB capacity |
eSATA | N/A |
Auxiliary Interface |
USB | 4/8CH:2 USB Ports (2 USB 2.0) |
16CH:2 USB Ports (1 USB 2.0,1 USB 3.0) |
RS232 | N/A |
RS485 | 1 Port, for PTZ Control |
Third-party Support |
Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
Audio and Video |
HDCVI Camera Input | 4/8/16 Channel |
IP Camera Input | 4+2/8+4/16+8 Channel, each channel up to 5MP |
Audio In/Out | 1/1, RCA |
Two-way Talk | Reuse audio in/out, RCA |
Recording |
Compression | H.264+/H.264 |
Resolution | 1080P, 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
Record Rate | Main Stream: 1080P(1-15fps), |
1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1-25/30fps) |
Sub steram:D1/CIF/QCIF(1-15fps) |
Bit Rate | 1Kbps - 6144Kbps Per Channel |
Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
Record Interval | 1 - 60 min (default: 60 min), Pre-record: 1 - 30 sec, Post-record: 10 - 300 sec |
Network |
Interface | 4/8CH:1 RJ-45 Port (100M) |
16CH:1 RJ-45 Port (1000M) |
Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
Max. User Access | 128 users |
Smart Phone | iPhone, iPad, Android |
Interoperability | ONVIF 2.42, CGI Conformant |
Electrical |
Power Supply | DC12V/2A |
Power Consumption | <15w hdd="" hari="" --15w--=""> |
Environmental |
Operating Conditions | -10°C - +55°C (+14°F - +131°F), 0- 90% RH |
Storage Conditions | -20°C - +70°C (-4°F - +158°F) , 0- 90% RH |
Construction |
Dimensions | Compact 1U, 260×236×48mm(10.2"×9.3"×1.9") |
Net Weight | 0.75kg ( 1.7lb) (without HDD) |
Gross Weight | 1.5kg (3.3lb) |
Installation | Desktop installation |
Certifications |
Certifications | FCC: Part 15 Subpart B ICES 003 Issue 6 |
CE: EN 55032: 2012+AC:2013 (Class B) |
EN 55024 : 2010 EN 61000-3-2 : 2014 |
EN 50130-4: 2011 EN 61000-3-3 : 2013 |
UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 |
