| System |
| Main Processor |
Embedded Processor |
| Operating System |
Embedded LINUX |
| Display |
| Interface |
1 HDMI(up to 3840x2160),1 VGA |
| Resolution |
3840x2160,1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display |
4CH: 1/4/6 |
| 8CH: 1/4/8/9/16 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video |
| |
Loss,Tampering and Diagnosis |
| Alarm input |
N/A |
| Relay Output |
N/A |
| Playback and Backup |
| Playback |
4CH: 1/4 |
| 8CH: 1/4/9 |
| Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
| Storage |
| Internal HDD |
1 SATA Port, up to 8TB capacity |
| eSATA |
N/A |
| Auxiliary Interface |
| USB |
2 USB Ports (1 USB 2.0 , 1 USB 3.0) |
| RS232 |
N/A |
| RS485 |
1 Port, for PTZ Control |
| Third-party Support |
| Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio and Video |
| HDCVI Camera Input |
4/8 Channel |
| IP Camera Input |
4+2/8+4 Channel, each channel up to 8MP |
| Audio In/Out |
1/1, RCA |
| Two-way Talk |
Reuse audio in/out, RCA |
| Recording |
| Compression |
H.264+/H.264 |
| Resolution |
4K, 4MP,1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate |
Main stream: 4K(1-15fps) |
| 4MP/1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF (1-25/30fps) |
| Sub steram:D1/CIF/QCIF(1-25/30fps) |
| Bit Rate |
1Kbps - 12288Kbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval |
1 - 60 min (default: 60 min), Pre-record: 1 - 30 sec, |
| Post-record: 10 - 300 sec |
| Network |
| Interface |
1 RJ-45 Port (1000M) |
| Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, |
| NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm |
| Server, P2P,IP Search (Support Dahua IP camera, |
| DVR, NVS, etc.) |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF 2.42, CGI Conformant |
| Electrical |
| Power Supply |
4CH: DC12V/2A, 8CH: DC12V/3A |
| Power Consumption |
<15w hdd="" hari="" --15w--=""> |
| Environmental |
| Operating Conditions |
-10°C - +55°C (+14°F - +131°F), 0- 90% RH |
| Storage Conditions |
-20°C - +70°C (-4°F - +158°F) , 0- 90% RH |
| Construction |
| Dimensions |
Mini 1U, 325mm×255mm×55mm (12.8" x 10" x 2.2") |
| Net Weight |
1.5kg (3.3 lb) (without HDD) |
| Gross Weight |
2kg (4.4lb) |
| Installation |
Desktop installation |
| Certifications |
| Certifications |
FCC: Coming Soon |
| CE: Coming Soon |
| UL: Coming Soon |
