| System |
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
| Display |
| Interface | 2 HDMI, 1 VGA, 1 TV |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display | 8CH: 1/4/8/9/16 |
| 16CH: 1/4/8/9/16/25 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm |
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis |
| Alarm input | 16 |
| Relay Output | 6 |
| Playback and Backup |
| Playback | 8CH: 1/4/9 |
| 16CH: 1/4/9/16 |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second), Smart search |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Storage |
| Internal HDD | 8 SATA Ports, up to 8TB capacity for each disk |
| eSATA | 1 Port |
| Auxiliary Interface |
| USB | 4 USB Ports (2 USB 2.0 , 2 USB 3.0) |
| RS232 | 1 port, for PC communication & Keyboard |
| RS485 | 1 Port, for PTZ Control |
| RS422 | 1 Port, for PTZ Control |
| Third-party Support |
| Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio and Video |
| HDCVI Camera Input | 8/16 Channel |
| IP Camera Input | 8+4/16+8 Channel, each channel up to 5MP |
| Audio In/Out | 8/16 Audio In, 1 Audio Out, BNC |
| Two-way Talk | 1 Mic In, 1 Mic Out, BNC |
| Recording |
| Compression | H.264+/H.264 |
| Resolution | 1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate | Main stream: 1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF (1-25/30fps) |
| Sub steram:D1/CIF/QCIF(1-25/30fps) |
| Bit Rate | 1Kbps - 6144Kbps Per Channel |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1 - 60 min (default: 60 min), Pre-record: 1 - 30 sec, Post-record: 10 - 300 sec |
| Network |
| Interface | 2 RJ-45 Port (1000M) |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 2.42, CGI Conformant |
| Electrical |
| Power Supply | AC100V-240V, 50/60Hz |
| Power Consumption | <35w without HDD |
| Environmental |
| Operating Conditions | -10°C - +55°C (+14°F - +131°F), 0- 90% RH |
| Storage Conditions | -20°C - +70°C (-4°F - +158°F), 0- 90% RH |
| Construction |
| Dimensions | 2U, 440mm×455mm×95mm (17.3" x 17.9" x 3.7") |
| Net Weight | 6.5kg (14.32 lb) (without HDD) |
| Gross Weight | 9.8kg (21.6lb) |
| Installation | Desktop installation/Rack-mounted |
| Certifications |
| Certifications | FCC: Part 15, Subpart B: 2015 |
| CE: EN 55032:2015(Class B), EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014, EN 61000-3-2:2014, EN61000-3-3:2013 |
| UL:EN60950-1:2006 + A1:2010 + A11:2009 + A12:2011 + |
| A2:2013 |
