System |
Main Processor | Embedded processor |
Operating System | Embedded LINUX |
Video and Audio |
Analog Camera Input | 16ch BNC |
AHD Camera | 1080N / 720P / 960H @25/30fps |
TVI Camera | 1080N / 720P / 960H @25/30fps |
CVI Camera | 1080N / 720P / 960H @25/30fps |
CVBS Camera | PAL/NTSC |
IP Camera Input | 16ch, each channel up to 1080P |
Audio In/Out | 6ch input, 1ch output, RCA |
Two-way Talk | N/A |
Display |
Interface | 1 HD-OUT, 1 VGA |
Resolution | HD-OUT: 1920×1080, 1280×1024, 1440×900 |
VGA: 1920×1080, 1280×1024, 1440×900 |
Multi-screen Display | 1/4/9/16 |
Recording |
Compression | H.265/H.264 |
Resolution | 1080N, 720P, 960H, D1 |
Record Rate | 1080N@15fps |
Bit Rate | 16Kbps ~ 4096Kbps Per Channel |
Record Mode | Manual, Event, Timer |
Record Interval | Post-record: 30 ~ 60s |
Video Detection and Alarm |
Trigger Events | Recording, Buzzer, Push message, Pop up message |
Video Detection | Motion Detection, Video Loss, Camera Tamper |
Alarm in/out | 4/1 |
Network |
Interface | 1 RJ-45 port (10/100Mbps) |
Network Function | HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP |
Max. User Access | Access 4 users |
Smart Phone | iPhone, iPad, Android |
Interoperability | ONVIF, SDK, CGI |
Playback and Backup |
Playback | 16/9/4/1 |
Search Mode | Time /Date, Alarm, Picture grid, Event |
Playback Function | Play, Pause, Stop, Next Frame, Fast play, Slow Play, Layout, Shuffle, Backup Selection, Digital Zoom |
Backup Mode | USB HDD |
Storage | |
Internal HDD | 2 SATA Ports, up to 8TB for each HDD |
Mounting Mode | Embedded |
eSATA | N/A |
Interface | |
USB | 2 ports (USB 2.0 x2) |
RS232 | N/A |
RS485 | 1 Port, for PTZ Control |
General |
Power Supply | DC12V/4A |
Power Consumption | Max 10W (without HDD) |
Operating Temperature | 0 °C ~ 50 °C (32 °F ~ 122 °F) |
Storage Conditions | Less than 90% RH |
Certifications | CE/FCC |
Dimensions | 350mm(L)x305mm(W)x49mm(H) |
Net Weight | 1.8Kg |
