| System |
| Main Processor | Embedded processor |
| Operating System | Embedded LINUX |
| Video and Audio |
| Analog Camera Input | 16ch BNC |
| AHD Camera | 5MP/4MP/3MP/1080P720P @25/30fps |
| TVI Camera | 5MP/4MP/3MP/1080P720P @25/30fps |
| CVI Camera | 5MP/4MP/3MP/1080P720P @25/30fps |
| CVBS Camera | PAL/NTSC |
| IP Camera Input | 16ch, each channel up to 1080P |
| Audio In/Out | 6ch input, 1ch output, RCA |
| Two-way Talk | N/A |
| Display |
| Interface | 1ch HD-OUT, 1ch VGA |
| Resolution | HD-OUT: 3840×2160, 1920×1080, 1280×1024, 1440×900 |
| VGA: 1920×1080, 1280×1024, 1440×900 |
| Multi-screen Display | 1/4/9/16 |
| Recording |
| Compression | H.265/H.264 |
| Resolution | 5MP-N, 4MP-N, 1080P, 720P, 960H, D1, CIF |
| Record Rate | 5MP-N@10fps, 4MP-N@15fps, 1080P @15fps |
| Bit Rate | 16Kbps~4096Kbps |
| Record Mode | Manual, Event, Timer |
| Record Interval | Post-record: 30 ~ 60 sec |
| Video Detection and Alarm |
| Trigger Events | Recording, Buzzer, Push message, Pop up message |
| Video Detection | Motion Detection, Video Loss, Camera Tamper |
| Alarm in/out | 4/2 |
| Network |
| Interface | 1 RJ-45 port (10/100Mbps) |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP |
| Max. User Access | Access 4 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF, SDK, CGI |
| Playback and Backup |
| Playback | 16/9/4/1 |
| Search Mode | Time/Date, Alarm, Picture grid, Event |
| Playback Function | Play, Pause, Stop, Next Frame, Fast play, Slow Play, Layout, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB HDD |
| Storage |
| Internal HDD | 2 SATA Ports, up to 8TB for each HDD |
| Mounting Mode | Embedded |
| eSATA | N/A |
| Interface |
| USB | 2 ports (USB 2.0 x2) |
| RS232 | N/A |
| RS485 | 1 Port, for PTZ Control |
| General |
| Power Supply | DC12V/4A |
| Power Consumption | Max 10W (without HDD) |
| Operating Temperature | -10 °C ~ 50 °C (14 °F ~ 122 °F) |
| Storage Conditions | Less than 90% RH |
| Certifications | CE/FCC |
| Dimensions | 350mm(L)x305mm(W)x49mm(H) |
| Net Weight | 1.8Kg |
