System |
Time Accuracy : 5ppm (12.5sec/month) |
Time Sync. : NTP, GMT, DST, Time Server |
User : 15 Users (Admin., User1 ~ User14) |
Camera |
IP Camera : ONVIF 2.2 (Profile-S) |
POE : 8 PoE |
Video |
Input : 16 IPC |
Display Rate : Max. 120/100fps |
Output Interface : HDMI, VGA, BNC |
Output Resolution : Full HD, XGA |
Spot : N/A |
Audio |
Input Interface : 16 IPC |
Output Interface : 1 HDMI |
Video Recording |
Speed : Max. 1080p 480fps |
Resolution : 1080p, 720p, 960H |
Quality : Depends on IPC |
Bit Rate : Max. 3Mbps/Ch |
Audio Recording |
Compression : Depends on IPC |
Network |
Interface : Ethernet 10/100/1G |
Compression : H.264 |
Speed : Max. D1 30fps total |
Resolution : Max. 1080p |
Alarm |
Post-Alarm : 5sec~5min |
Motion Grid : Depends on IPC |
Alarm Action : E-mail, Event Popup, Buzzer, Relay, PTZ Preset, Spot, Front LED |
Input / Output : 4/1 - NC/NO/EOL |
Display |
HDMI : Full HD, XGA |
VGA : Full HD, XGA |
TV : SDTV (720x480/576) |
External Interface |
PTZ / Keyboard : 1 RS485 - Terminal Block |
ATM/POS : RS232C - Terminal Block |
Storage |
Primary, External, ODD : 6 HDD, 2 eSATA, 1 DVD |
General |
OS : Embedded Linux |
Dimension : 440 x 88 x 430 mm |
Net Weight(w/o HDD) : 8Kg |
Power Supply : 90~250V, 50/60Hz |
Consumption : 80Watts |
Input Voltage(PoE) : DC48V / 2A |
Camera Power output : Max. 30 W per channel, Up to Total 80W |
Operating Temp : 5 ~ 40˚C |
Humidity : 10 ~ 80% |
