Video/Audio Input |
IP Video Input | 16-ch |
Two-way Audio Input | 1-ch, RCA |
Network |
Incoming Bandwidth | 80Mbps |
Outgoing Bandwidth | 80Mbps |
Remote Users | 128 |
Video/Audio Output |
HDMI/VGA Output | HDMI: |
4K(3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
VGA: |
1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch, RCA |
Synchronous Playback | 16-ch |
Decoding |
Compression | H.265/H.264 |
Live view/Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30, 16 x D1 |
Hard Disk |
SATA | 1 SATA interface |
Capacity | up to 8TB for each disk |
External Interface |
Network Interface | 1 RJ-45 10M/100M Self-adaptive Ethernet Interface |
USB Interface | Rear panel: 2 x USB2.0, Front panel: 1 x USB2.0 |
Alarm In | 4-ch |
Alarm Out | 1-ch |
General |
Power Supply | 12V DC |
Consumption | ≤ 8 W |
Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
Working Humidity | 10% ~ 90% |
Dimensions | 44 × 260 × 240mm ( 1.7" × 10.2" × 9.4" ) |
Weight ( without HDD ) | ≤ 1.12 Kg ( 2.47 lb ) |
