| Video/Audio Input |
| IP Video Input | 16-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 60Mbps |
| Outgoing Bandwidth | 80Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI: |
| 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 16-ch |
| Decoding |
| Compression | H.265/H.264 |
| Live view/ | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Playback |
| Capability | 1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30, 16 x D1 |
| Hard Disk |
| SATA | 1 SATA interface |
| Capacity | up to 8TB for each disk |
| External Interface |
| Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel：2 x USB2.0 |
| PoE |
| Interface | 8 independent 100 Mbps PoE network interfaces |
| Max Power | Max 30W for single port |
| Max 108W in total ( 13.5W for each ) |
| Supported Standard | IEEE 802.3at, IEEE 802.3af |
| General |
| Power Supply | 52V DC |
| Consumption | ≤ 8 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 42 × 270 × 205mm ( 1.7" × 10.6" × 8.1" ) |
| Weight ( without HDD ) | ≤ 0.68 Kg ( 1.50 lb ) |
