| Video/Audio Input |
| IP Video Input |
16-ch |
| Two-way Audio Input |
1-ch, RCA |
| Network |
| Incoming Bandwidth |
160Mbps |
| Outgoing Bandwidth |
320Mbps |
| Remote Users |
128 |
| Video/Audio Output |
| HDMI/VGA Output |
HDMI1/VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| HDMI2: |
| 4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output |
1-ch, RCA |
| Synchronous Playback |
16-ch |
| Decoding |
| Compression |
H.265/H.264 |
| Live view/ Playback |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability |
4 x 12MP@20, 4 x 4K@30, 8 x 4MP@20, 16 x 1080p@25, 32 x 720p@25 |
| Hard Disk |
| SATA |
4 SATA interfaces |
| Capacity |
up to 8TB for each HDD |
| External Interface |
| Network Interface |
2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces |
| Serial Interface |
1 x RS485 |
| USB Interface |
Front panel: 1 x USB2.0 |
| Rear panel: 1 x USB2.0, 1 x USB3.0 |
| Alarm In |
16-ch |
| Alarm Out |
4-ch |
| General |
| Power Supply |
12V DC |
| Consumption |
≤ 12 W |
| Working Temperature |
-10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity |
10% ~ 90% |
| Dimensions |
44 × 440 × 344mm ( 1.7" × 17.3" × 13.5" ) |
| Weight ( without HDD ) |
≤ 3.14 Kg ( 6.92 lb ) |
