| System |
Embedded LINUX Embedded LINUX |
| Operating System |
Video & Audio Video & Audio |
| IP Camera Input |
32 channel |
| Two-way Talk |
1 channel Input, 1 channel Output, BNC 1 channel Input, 1 channel Output, BNC |
| Interface |
1 HDMI, 1 VGA, 1 BNC |
| Resolution |
800*600; 1024*768; 1280* 1024; 1440*900; 1920* 1080 |
| Display Split |
1/4/8/16 1/4/8 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Compression |
H.264 (High Profile@Level4.2) / MPEG-4 |
| Resolution |
1080P(1920x 1080) / 720P(1280x720) / D1 (704x576/704x480) |
| Record Rate |
Max 8CH@1080P or 16CH@720P or 16CH@D1 Max 16CH@1080P or 32CH@720P or 32CH@D1 |
| Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Trigger Events |
Recording, Alarm, Video Push, Email, Buzzer |
| Video Detection |
Motion Detection* Video Loss* HDD Loss |
| Alarm Input |
4 channel |
| Relay Output |
1 channel |
| Sync Playback |
8CH D1 or 4CH 720P or 1CH 1080P 8CH D1 or 4CH 720P or 1CH 1080P |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second) |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, |
| Backup Mode |
USB Device / Network Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Ethernet |
RJ-45 port (10/100M) |
| Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, DHCP, DNS, PPPOE, DDNS |
| Max.User Access |
20 users |
| Mobile Phone |
IPhone, IPad, Android IPhone, IPad, Android |
| Internal HDD |
8 SATA ports, up to 4TB |
| USB Interface |
3 ports (1 Rear), USB2.0 |
| RS232 |
Yes Yes |
| RS485 |
1 port, For PTZ control |
| Power Supply |
DC12V/2A DC12V/4A |
| Power Consumption |
10W(without HDD) 10W(without HDD) |
| Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa -10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension(W*D*H) |
255*230*47 (mm) 1U, 315*274*45 (mm) |
| Weight |
1.2-1.5kg(without HDD) 1.5-2.0kg(without HDD) |
| Network cable |
4*18M |
