Video/Audio Input |
IP video input: |
32-ch |
Two-way audio input: |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
Network |
Incoming bandwidth: |
256Mbps |
Outgoing bandwidth: |
256Mpbs |
Remote connection: |
128 |
Video/Audio Output |
Recording Resolution: |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Audio Output: |
1-ch, RCA (2.0Vp-p, 1KΩ) |
Synchronous Playback: |
16-ch |
VGA Output: |
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
Decoding |
Live view / Playback: |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Capability: |
4-ch@8MP,16-ch@1080P |
Hard Disk |
SATA: |
4 SATA interfaces for 4HDDs |
Capacity: |
Up to 6TB capacity for each HDD |
External Interface |
Network Interface: |
1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
Serial Interface: |
RS-232; RS-485; |
USB Interface: |
Front panel: 2 × USB 2.0 |
Rear panel: 1 × USB 3.0 |
Alarm In: |
16-ch |
Alarm Out: |
4-ch |
POE |
Interface: |
16 independent 10/100 Mbps PoE Ethernet interfaces |
Max. Power: |
200W |
Supported Standard: |
AF and AT |
General |
Power Supply: |
100 to 240 VAC |
Consumption(without hard disk and POE): |
≤20 W |
Working Temperature: |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
Working Humidity: |
10 % ~ 90 % |
Chassis: |
19-inch rack-mounted 1.5U chassis |
Dimensions: |
445 × 390 × 70 mm (17.5"× 15.3" × 2.8") |
Weight(without HDD): |
≤ 5 Kg (11 lb) |
