| Video/Audio Input |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input | 32-ch |
| Network |
| Incoming bandwidth | 256Mbps |
| Outgoing bandwidth | 256Mbps |
| Video/Audio Output |
| HDMI/VGA output | 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 ×1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz. 4K resolution is only available for HDMI. |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 16-ch |
| Decoding |
| Decoding format | H.265+/H.265/ H.264+/H.264 |
| Capability | 12-ch @ 1080p |
| Hard Disk |
| SATA | 2 SATA interfaces |
| Capacity | Up to 8TB capacity for each HDD |
| External Interface |
| Network Interface | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| USB Interface | Front panel 1 × USB 2.0 |
| Rear panel 1 × USB 3.0 |
| Alarm In | 4-ch |
| Alarm Out | 1-ch |
| General |
| Power Supply | 12 VDC |
| Power | ≤ 40 W |
| Consumption(without hard disk and POE) | ≤ 15 W |
| Working Temperature | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity | 10 % ~ 90 % |
| Dimensions | 380 × 315 × 51.5 mm ( 15.0"× 12.4" × 2.0") |
| Weight(without HDD) | ≤ 3 kg (6.6 lb) |
