| Video/Audio Input |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input | 32-ch |
| Network |
| Incoming bandwidth | 320Mbps |
| Outgoing bandwidth | 256Mbps |
| Video/Audio Output |
| HDMI/VGA output | 4-ch, VGA1 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; HDMI1 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560× 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; VGA2/HDMI2 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×768/60Hz |
| CVBS Output | 1-ch, BNC(1.0Vp-p, 75Ω) |
| Resolution 704×576(PAL); 704×480(NTSC) |
| Synchronous Playback | 16-ch |
| Decoding |
| Capability | 16-ch @ 1080p |
| Live view / Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Hard Disk |
| eSATA | 1 eSATA interface |
| SATA | 8 SATA interfaces for 8 HDDs |
| Capacity | Up to 10TB capacity for each HDD |
| Disk array |
| Array type | RAID0, RAID1, RAID5, RAID6, RAID10 |
| External Interface |
| Network Interface | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface | RS-232, RS-485, Keyboard |
| USB Interface | Front panel 2 × USB 2.0 |
| Rear panel 1 × USB 3.0 |
| Alarm In | 16-ch |
| Alarm Out | 4-ch |
| General |
| Power Supply | 220 VAC |
| Power | 200 W |
| Consumption(without hard disk and POE) | ≤ 70 W |
| Working Temperature | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity | 10 % ~ 90 % |
| Chassis | 19-inch rack-mounted 2U chassis |
| Dimensions | 445 × 470 ×90 mm (17.5"× 18.5" × 3.5") |
| Weight(without HDD) | ≤ 10 kg (22 lb) |
