| Video/Audio Input |
| IP Video Input | 32-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 200Mbps |
| Outgoing Bandwidth | 96Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI/VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 16-ch |
| Decoding |
| Compression | H.264 |
| Live view/Playback | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 4 x 4MP@20, 6 x 1080p@25, 16 x 720p@25, 32 x D1 |
| Hard Disk |
| SATA | 4 SATA interfaces |
| Capacity | up to 6TB for each disk |
| External Interface |
| Network Interface | 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces |
| Serial Interface | 1 x RS485 |
| USB Interface | Front panel: 1 x USB2.0 |
| Rear panel: 1 x USB2.0, 1 x USB3.0 |
| Alarm In | 8-ch |
| Alarm Out | 2-ch |
| General |
| Power Supply | 12V DC |
| Consumption | ≤ 8 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 44 × 440 × 341mm ( 1.7” × 17.3” × 13.4” ) |
| Weight ( without HDD ) | ≤ 3.09 Kg ( 6.81 lb ) |
