| Video/Audio Input |
| IP Video Input |
32-ch |
| Two-way Audio Input |
1-ch, RCA |
| Network |
| Incoming Bandwidth |
320Mbps |
| Outgoing Bandwidth |
320Mbps |
| Remote Users |
128 |
| Video/Audio Output |
| HDMI/VGA output |
HDMI1/VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| HDMI2: |
| 4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output |
1-ch, RCA |
| Synchronous Playback |
16-ch |
| Decoding |
| Compression |
H.265/H.264 |
| Live view/Playback |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability |
4 x 12MP@20, 4 x 4K@30, 8 x 4MP@20, 16 x 1080p@25, 32 x 720p@25> |
| Hard Disk |
| SATA |
4 SATA interfaces |
| Capacity |
up to 8TB for each HDD |
| External Interface |
| Network Interface |
1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface |
| Serial Interface |
1 x RS485 |
| USB Interface |
Front panel: 2 x USB2.0 |
| Rear panel: 1 x USB3.0 |
| Alarm In |
16-ch |
| Alarm Out |
4-ch |
| Power Output |
12 VDC |
| PoE |
| Interface |
16 independent 100 Mbps PoE network interfaces |
| Max Power |
Max 30W for single port |
| Max 200W in total ( 12.5W for each ) |
| Supported Standard |
IEEE 802.3at |
| General |
| Power Supply |
100 ~ 240 VAC |
| Consumption |
≤ 20 W |
| Working Temperature |
-10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity |
10% ~ 90% |
| Dimensions |
86 × 442 × 425mm (3.4" × 17.4" × 16.7" ) |
| Weight ( without HDD ) |
≤ 5.24 Kg ( 11.55 lb ) |
