| System |
| Main Processor |
Quad-core embedded processor |
| Operating System |
Embedded LINUX |
| Aduio and Video |
| IP Camera Input |
4 Channel |
| Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 |
| VGA: 1920×1080, 1280×1024, 1280×720 |
| Decoding Capacity |
2ch@4K 30fps, 8ch@1080P 30fps |
| Multi-screen Display |
1.Nis |
| OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
H.265/ H.264 |
| Resolution |
8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. |
| Record Rate |
200Mbps |
| Bit Rate |
16Kbps ~ 20Mbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: |
| 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), |
| Video Loss and Tampering |
| Alarm input |
4 Channel |
| Relay Output |
2 Channel |
| Playback and Backup |
| Playback |
1.4 |
| Search Mode |
Time /Date, MD and Exact Search |
| (accurate to second), Smart search |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, |
| Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
| Third-party Support |
| Third-party Support |
Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more |
| Network |
| Interface |
1 RJ-45 Port (10/100/1000Mbps) |
| Ethernet Port |
1 Independent 1000Mbps Ethernet Port |
| PoE |
4 ports (IEEE802.3at/af) |
| Network Function |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF 2.4, SDK, CGI |
| Storage |
| Internal HDD |
2 SATA III Ports, Up to 6 TB capacity for each HDD |
| HDD Mode |
Single |
| Auxiliary Interface |
| USB |
2 ports(1 USB2.0, 1 USB3.0) |
| RS232 |
N/A |
| RS485 |
N/A |
| Electrical |
| Power Supply |
DC48V/2A |
| Power Consumption |
NVR: < 9W(without HDD) |
| PoE: Max 25.5w for single port, 50w in total |
| Environmental |
| Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
| Construction |
| Dimensions |
1U, 375mm×281.5mm×56mm |
| (14.8" x 11.1" x2.2") |
| Net Weight |
1.6kg (3.5 lb) (without HDD) |
| Gross Weight |
3.2kg(7.1 lb)(without HDD) |
| Certifications |
| CE |
EN55032, EN55024, EN50130-4, EN60950-1 |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| UL |
UL60950-1 |
