| System |
| Main Processor | Dual-core embedded processor |
| Operating System | Embedded LINUX |
| Audio and Video |
| IP Camera Input | 4/8 Channel |
| Two-way Talk | N/A |
| Display |
| Interface | 1 HDMI, 1 VGA |
| Resolution | 1920×1080, 1280×1024, 1280×720 |
| Decoding Capacity | 1ch@6MP 30fps, 4ch@1080P 25fps |
| Multi-screen Display | 4CH: 1/4 |
| 8CH: 1/4/8/9 |
| OSD | Camera title, Time, Camera lock, Motion detection, Recording |
| Recording |
| Compression | H.265+/H.264+ |
| Resolution | 6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc. |
| Record Rate | 40Mbps |
| Bit Rate | 16Kbps - 20Mbps Per Channel |
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Stop |
| Record Interval | 1-120 min (default: 60 min), Pre-record: 1-30 sec, Post-record: 10-300 sec |
| Video Detection and Alarm |
| Trigger Events | Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), |
| and Tampering |
| Alarm input | N/A |
| Relay Output | N/A |
| Playback and Backup |
| Sync Playback | 4CH: 1/4 |
| 8CH: 1/4/9 |
| Search Mode | Time /Date, MD and Exact Search |
| (accurate to second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
| Third-party Support |
| Third-party Support | Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
| Network |
| Interface | 1 RJ-45 port (10/100Mbps) |
| Network Function | HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, IP Search(Support Dahua IP camera, DVR, NVS and etc.), P2P |
| Optical Fiber Interface | N/A |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF ,SDK, CGI Conformant |
| Storage |
| Internal HDD | 1 SATA III Port, up to 4TB capacity for each HDD |
| HDD Mode | Single |
| eSATA | N/A |
| Auxiliary Interface |
| USB | 2 ports (2 Rear USB2.0) |
| RS232 | N/A |
| RS485 | N/A |
| Electrical |
| Power Supply | Single, DC12V/1.5A |
| Power Consumption | <2.57w without="" hdd="" td=""> |
| Environmental |
| Operating Conditions | -10°C - +45°C (+14°F - +113°F), 86 - 106kpa |
| Storage Conditions | -20°C - +70°C (-4°F - +158°F), 0 - 90% RH |
| Construction |
| Dimensions(W×D×H) | Cooper 1U, 197mm×196.6mm×41.5mm |
| (7.76" x 7.74" x 1.63") |
| Net Weight | 1.15 kg (2.54 lb) (without HDD) |
| Gross Weight | 1.65kg(3.64 lb)(without HDD) |
| Certifications |
| CE | EN55032, EN55024, EN50130-4, EN60950-1 |
| FCC | Part 15 Subpart B, ANSI C63.4-2014 |
