Özellikler
- Built in PoE Switch for direct IP camera connection
- Multiplex (Live/Playback, Recording, Backup, Networking)
- Various recording features (Normal, schedule, motion, alarm)
- Controlled locally by USB mouse or remotely through Ethernet connection with CMS, Web page and Smartphone
- NAS Support to extend storage capacity
- Recorded files backup via USB device
- ONVIF protocol support (Profile S & G)
- SDK for Windows and Linux system
Teknik Özellikler
- Operating System: Embedded OS
- IP Inputs: 4 channels
- Video Outputs: 1x VGA, 1x HDMI
- Harddisk bay: 1 x SATA II
- Max. Storage Capacity: 12 TB (1x4 TB SATA, 8x1TB NAS)
- Video Compression: H.264
- Recording Resolution: VGA (640x480), 4CIF (704x576), 720p (1280x720), 1.3MP (1280x960), UXGA (1600x1200), 1080p (1920x1080), QXGA (2048x1536), 5MP (2560x1920)
- Recording Bandwidth: max. 40 Mbps
- Outgoing Bandwidth: max. 80 Mbps
- Recording Mode: Continuous, Event Alarm, Motion, Video Loss, Schedule
- Display Resolution: Up to 1920x1080 (HDMI / VGA)
- Display Speed: 4ch @ 1080p
- Playback: Synchronised playback of max. 4 cameras
- Search Mode: Date/Time, Event Alarm, Motion, Search Backup
- External Backup: USB HDD, USB Memory, USB DVD-ROM, Network
- Watermark: Yes
- Motion Detection: On/ Off/ Area Setting
- Event Source: Motion, Alarm, Video Loss, System
- Event Action: Pop-Up, Relay, E-Mail, Buzzer, PTZ Preset
- PTZ Control: Pan/Tilt/Zoom, Camera OSD, Preset set/call
- Audio Inputs: 4 CH over IP, 1x RCA
- Audio Outputs: 1 CH, RCA
- Audio Compression: G.711
- Alarm Inputs: 4 contact input N/O or N/C
- Alarm Outputs: 1 Relay
- ONVIF compliant: Profile S, Profile G
- Network Interface: 4x 10/100 Base T/TX PoE (RJ-45) + 1x 10/100/1000 Base T/TX (RJ-45)
- PoE Budget: 50 W, max. 15W on a single port
- Remote Connections: Up to 128 (depending on available outgoing bandwith)
- Network Protocol: IPv4, IPv6, TCP/IP, UDP, RTP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI
- Serial Interface(s): 1x USB 2.0, 1x USB 3.0
- Multiplex Function: Triplex
- Client software: Windows (Vista, 7, 8), Web Viewer: IE, Firefox, Safari, Chrome; Mobile: iOS, Android
- Operating Temperature: -10°C ~ +55°C
- Operating Humidity: 10% ~ 90%, non-condensing
- Supply Voltage: 48 Vdc
- Power Consumption: 10 (without HDD and PoE) W
- Weight: 1 kg
- Dimensions w*h*d: 380 x 290 x 48 mm
Grundig GRN G1004P NVR Kayıt Cihazı PDF Dosyası319.18 KB
