| Video/Audio Input |
| Audio Input : 1-ch, RCA (2.0Vp-p, 1kΩ) |
| Two-way Audio : 2-ch, BNC(2.0Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth : 25Mbps |
| Outgoing bandwidth : 40Mbps |
| Remote connection : 128 |
| Video/Audio Output |
| HDMI/VGA output : 1-ch, resolution:1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,1024 × 768 /60Hz |
| Recording Resolution : 5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output : 1-ch, RCA (Linear, 1kΩ) |
| Synchronous Playback : 4-ch @ 720P, 2-ch @ 1080P, 1-ch @ 5MP |
| Decoding |
| Live view / Playback : 5MP/3MP/1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Hard Disk |
| SATA : 1 SATA interface for 1 HDD |
| Capacity : Up to 4TB capacity for each HDD |
| External Interface |
| Antenna Interface : 1, with wireless AP function |
| Network Interface : 1 RJ-45 10 / 100 Mbps selfadaptive |
| Ethernet interface |
| USB Interface : 2, USB2.0 |
| General |
| Power Supply : 12V DC |
| Consumption(without hard disk and POE) : ≤ 15 W |
| Working Temperature : -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity : 10 % ~ 90 % |
| Chassis : 1U chassis |
| Dimensions : 200 × 200 × 45 mm |
| Weight(without HDD) : ≤ 1 Kg |
