| Video/Audio Input |
| IP video input: |
4-ch |
| Two-way audio input: |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth: |
40Mbps |
| Outgoing bandwidth: |
80Mbps |
| Video/Audio Output |
| Recording Resolution: |
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output: |
1-ch, RCA (Linear, 1kΩ) |
| VGA Output: |
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Decoding |
| Live view / Playback: |
8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: |
4-ch@1080P |
| Hard Disk |
| SATA: |
1 SATA interface for 1 HDD |
| Capacity: |
Up to 6TB capacity for each HDD |
| External Interface |
| Network Interface: |
1 RJ-45 10 / 100 Mbps selfadaptive |
| |
Ethernet interface |
| USB Interface: |
2, USB2.0 |
| POE |
| Interface: |
4 independent 10 /100 Mbps PoE |
| |
Ethernet interfaces |
| General |
| Power Supply: |
48 VDC |
| Consumption(without hard disk and POE): |
≤ 10 W |
| Working Temperature: |
ºC ~ +40 ºC (+32 ºF ~ +104 ºF) |
| Working Humidity: |
10 % ~ 90 % |
| Chassis: |
315 mm chassis |
| Dimensions: |
315 × 240 × 48 mm (12.4" × 9.4" × 1.9") |
| Weight(without HDD): |
≤ 1 kg (2.2 lb) |
