| System |
| Main Processor | Dual-core embedded processor |
| Operating System | Embedded LINUX |
| Video & Audio |
| IP Camera Input | 4 channel |
| Two-way Talk | 1 channel Input, 1 channel Output, RCA |
| Display |
| Interface | 1 HDMI, 1 VGA |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Display Split | 1.4 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Compression | H.264 / MJPEG |
| Resolution | 1080P(1920 x 1080) / 720P(1280×720) / D1(704×576/704×480) & etc. |
| Record Rate | 120fps @ 1080P, 240fps @ 720P, 480fps @ D1> |
| Bit Rate | 48~8192kbps |
| Record Mode | Manual, Schedule(Regular(Continuous), MD), Stop |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Buzzer & Screen tips |
| Video Detection | Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
| Alarm Input | 2 channel |
| Alarm Output | 1 channel |
| Playback & Backup |
| Sync Playback | 1 / 4 / 9 |
| Search Mode | Time/Date, MD & Exact search (accurate to second), Smart search |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device / Network |
| Network |
| Ethernet | 1 RJ-45 port (10/100Mbps) |
| Network Function | HTTP, TCP/IP, IPv4/Ipv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search (Support Dahua IP camera, DVR, NVS and etc.) |
| Max. User Access | 20 users |
| Smart Phone | iPhone, iPad, Android, Windows Phone |
| Storage |
| Internal HDD | 1 SATA port, up to 4TB |
| Auxiliary Interface |
| USB | 2 ports (1 Rear), USB2.0 |
| General |
| Power Supply | NVR: DC12V/2A |
| Power Consumption | NVR: 12W (without HDD) |
| Working Environment | °C~+50°C/10%~90%RH/86~106kpa |
| Dimension (W×D×H) | Mini 1U, 325mm×240mm×45mm |
| Weight | 1.25kg (Without HDD) |
