System |
Main Processor | Dual-core embedded processor |
Operating System | Embedded LINUX |
Video |
IP Camera Input | 4 channel |
Two-way Talk | 1channel Input, 1channel Output, RCA |
Display |
Interface | 1 HDMI,1 VGA |
Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
Display Split | 1.4 |
OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
Recording |
Compression | H.264/MJPEG |
Resolution | 5Mp(2560×1920)/3Mp(2048×1536)/1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)&etc. |
Record Rate | 200Mbps |
Bit Rate | 48~ 8192kbps |
Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection & Alarm |
Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email,FTP, Buzzer & Screen tips |
Video Detection | Motion Detection,MD Zones: 396(22×18), Video Loss & Camera Blank |
Alarm Input | 4 channel |
Relay Output | 2 channel |
Playback & Backup |
Sync Playback | 1 / 4 / 9 |
Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
Backup Mode | USB Device/Network/Internal SATA burner |
Network |
Ethernet | 1 RJ-45 port (10/100/1000Mbps) |
Network Function | HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
Max. User Access | 128users |
Smart Phone | iPhone, iPad, Android, Windows Phone |
Storage |
Internal HDD | 2 SATA ports, up to 8TB |
Auxiliary Interface |
USB | 2 ports (1 Rear USB3.0, 1 Front USB2.0) |
RS232 | 1 port, For PC communication&Keyboard |
RS485 | 1 port, For PTZ control |
General |
Power Supply | DC12V/4A |
Power Consumption | 20W(without HDD) |
Working Environment | -10°C ~+55°C / 10%~90%RH / 86~106kpa |
Dimension | 1U, 375mm×285mm×50mm |
(W×D×H) |
Weight | 2.0KG(without HDD) |
