| Video /Audio Input |
| IP Video Input | 4-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 25Mbps |
| Outgoing Bandwidth | 16Mbps |
| Remote Connection | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI/VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Audio Output | 1-ch, RCA |
| Recording Resolution | 1080p/960p/720p/D1/2CIF/CIF |
| Synchronous Playback | 4-ch |
| Decoding |
| Compression | H.264 |
| Live view/ Playback | 1080p/960p/720p/D1/2CIF/CIF |
| Capability | 1*1080P@30, 3*960P@25, 4*720P@25, 8*D1 |
| Hard Disk |
| SATA | 1 SATA interface |
| Capacity | up to 6TB for each disk |
| External Interface |
| Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel: 2 x USB2.0 |
| General |
| Power Supply | 12V DC |
| Consumption ( without HDD ) | ≤ 4 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 44 × 215 × 260mm ( 1.7" × 8.5" × 10.2") |
| Weight ( without HDD ) | ≤ 0.79 Kg ( 1.74 lb ) |
