Video/Audio Input |
IP Video Input | 64-ch |
Two-way Audio Input | 1-ch, RCA |
Network |
Incoming Bandwidth | 320Mbps |
Outgoing Bandwidth | 320Mbps |
Remote Users | 128 |
Video/Audio Output |
HDMI/VGA Output | HDMI1/VGA: |
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
HDMI2: |
4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
CVBS Output | 1-ch, BNC |
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch, RCA |
Synchronous Playback | 16-ch |
Decoding |
Compression | H.265/H.264 |
Live view/ Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 3 x 12MP@25, 4 x 4K@30, 8 x 4MP@30, 16 x 1080P@30, 32 x 960P@25, 36 x 720P@30, 64 x D1 |
Hard Disk |
SATA | 8 SATA interfaces |
Capacity | up to 8TB for each HDDs |
eSATA | 1 eSATA interface |
Disk Array |
Array Type | RAID 0, 1, 5, 6, 10 |
External Interface |
Network Interface | 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Interfaces |
Serial Interface | 1 x RS232, 1 x RS485 |
USB Interface | Front panel: 2 x USB2.0,Rear panel: 1 x USB3.0 |
Alarm In | 16-ch |
Alarm Out | 4-ch |
General |
Power Supply | 100 ~ 240 VAC |
Consumption | ≤ 20 W |
Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
Working Humidity | 10% ~ 90% |
Dimensions | 86mm × 442mm ×425mm ( 3.4" × 17.4" × 16.7" ) |
Weight ( without HDD ) | ≤ 5.13 Kg (11.31 lb ) |
