System |
Main Processor |
Dual-core embedded processor |
Operating System |
Embedded LINUX |
Audio and Video |
IP Camera Input |
8 Channel |
Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
Display |
Interface |
1 HDMI, 1 VGA |
Resolution |
HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 |
VGA: 1920×1080, 1280×1024, 1280×720 |
Decoding Capacity |
1ch@8MP 30fps, 4ch@1080P 30fps |
Multi-screen Display |
1/4/8/9 |
OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
Recording |
Compression |
H.265/H.264 |
Resolution |
8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc. |
Record Rate |
80Mbps |
Bit Rate |
16Kbps ~ 20Mbps Per Channel |
Record Mode |
Manual, Schedule(Regular(Continuous), MD, Stop |
Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
Video Detection and Alarm |
Trigger Events |
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), |
and Tampering |
Alarm input |
N/A |
Relay Output |
N/A |
Playback and Backup |
Playback |
1.4 |
Search Mode |
Time /Date, MD and Exact Search |
(accurate to second) |
Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom |
Backup Mode |
USB Device/Network |
Third-party Support |
Third-party Support |
Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
Network |
Interface |
1 RJ-45 port (10/100/1000Mbps) |
PoE |
8 ports (IEEE802.3at/af) |
Network Function |
HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support Dahua IP camera, DVR, NVS and etc.), Easy4ip |
Optical Fiber Interface |
N/A |
Max. User Access |
128 users |
Smart Phone |
iPhone, iPad, Android |
Interoperability |
ONVIF 2.4, SDK, CGI |
Storage |
Internal HDD |
1 SATA III Port, up to 6TB capacity for each HDD |
HDD Mode |
Single |
eSATA |
N/A |
Auxiliary Interface |
USB |
2 ports (2 Rear USB2.0) |
RS232 |
N/A |
RS485 |
N/A |
Electrical |
Power Supply |
Single, DC48V/2A |
Power Consumption |
NVR: <5.8w without="" hdd="" --5="" 8w--=""> |
PoE: Max 25.5w for single port, 80w in total |
Environmental |
Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
Construction |
Dimensions(W×D×H) |
Smart 1U, 270mm×204.7mm×45.7mm |
(10.6" x 8.1" x 1.8") |
Net Weight |
0.65kg (1.43 lb) (without HDD) |
Gross Weight |
1.8kg(3.97 lb)(without HDD) |
Certifications |
CE |
EN55032, EN55024, EN50130-4, EN60950-1 |
FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
UL |
UL60950-1 |
