Video/Audio Input |
IP Video Input | 8-ch |
Network |
Incoming bandwidth | 48Mbps |
Outgoing bandwidth | 48Mbps |
Remote Users | 128 |
Video/Audio Output |
HDMI/VGA Output | HDMI: |
4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
VGA: |
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
Audio Output | 1-ch, RCA |
Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Synchronous Playback | 8-ch |
Decoding |
Compression | H.265/H.264 |
Live view/ Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30> |
Hard Disk |
SATA | 1 SATA interface |
Capacity | up to 8TB for each disk |
External Interface |
Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
USB Interface | Rear panel:1 x USB2.0, Front panel:1 x USB2.0 |
General |
Power Supply | 12V DC |
Consumption ( without HDD ) | ≤ 5 W |
Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
Working Humidity | 10% ~ 90% |
Dimensions | 43.6mm × 240.2mm × 260.0mm ( 1.7" × 9.5" × 10.2" ) |
Weight ( without HDD ) | ≤ 1 Kg (2.2 lb ) |
